19" On-Wall SOHO ACP cabinets are an alternative to traditional wall cabinets, offering better aesthetics.
19" SOHO On-Wall ACP cabinets are designed for installation directly on the wall. Suitable for a wide range of use cases, these cabinets offer a more elegant design and a cost-effective solution for developers/home owners.
| Product line name |
SOHO On-Wall ACP |
|---|---|
| Height (mm) |
550
|
| Width (mm) |
530
|
| Tiefe (mm) |
155
|
| Konstrukce |
Cabinet and door made of 1.25mm, 1.5mm and 2mm sheet metal |
| Color design |
Powder color RAL 7035 (other colors available upon request) |
| Standard configuration |
1 pair of fixed 19"" vertical rails (4U) |
Binding panels with plastic loops are used for installation and horizontal routing of cables within the cabinet.
Plastic binding ducts are intended for placement and horizontal routing of cables in rack cabinets, wall-mounted and SOHO cabinets.
Binding panel with metal loops, single-sided design only
Optical trays are used to terminate optical cables in the cabinet. We also offer various types of modular panels and other optical accessories.
All CONTEG cabinets include a basic grounding kit in the standard configuration.
Patch panels are attached to 19" vertical rails and allow the termination of data or telephone cables to different types of modules.
3 types of patch panels
Accessories for SOHO Mini REH - binding panel.
